Thiết bị máy đo chỉ số chảy MFR của nhựa và cao su model No.140-SAS

Model

No.140-SAS LIGHT LOAD

No.140-SAS HEAVY LOAD

Hangings

1 or 3 Hangings (2 kinds)

1 or 3 Hangings (2 kinds)

Maximum Load

Max. 10 kN

Max. 20 kN

Load Measuring

Load Cell: Max. 10 kN (Scale 0.1 kN)

Load Cell, Max. 20 kN (Scale 0.1 kN)

Ram Speed

0.5 to 500 mm/min

0.5 to 1,000 mm/min

Capillary Die

φ0.5 to φ2 mm, L/D (To be specified)

φ0.5 to φ2 mm, L/D (To be specified)

Piston

φ9.510 ± 0.005 mm, L6.35 ± 0.10 mm

φ9.510 ± 0.005 mm, L6.35 ± 0.10 mm

Cylinder

Inner φ9.550 ± 0.025 mm, L160 mm

Inner φ9.550 ± 0.025 mm, L200 mmm

Temperature Range

Max. 400 °C

Max. 400 °C

Software

Windows Compatible

Windows Compatible

Accessories

Cleaning Rod (Die & Cylinder), Solvent Cleaning Device, Specimen Cup, Cup Holder, Infundibulum, Die Gauge, Spirit Level, Dust Box, Gauze, Air Gun, Ratchet Wrench

Cleaning Rod (Die & Cylinder), Solvent Cleaning Device, Specimen Cup, Cup Holder, Infundibulum, Die Gauge, Spirit Level, Dust Box, Gauze, Air Gun, Ratchet Wrench

Option

Hastelloy Spec, Specimen Purging Device, Specimen Drying Device, Air Compressor, Temperature Calibration Device, Exhaust Fan, Smoke-Detection Sensor

Hastelloy Spec, Specimen Purging Device, Specimen Drying Device, Air Compressor, Temperature Calibration Device, Exhaust Fan, Smoke-Detection Sensor

Power Source

AC 200 V, 1-Phase, 10 A, 50/60 Hz

AC 200 V, 1-Phase, 10 A, 50/60 Hz

Air Source

0.5 MPa or More

0.5 MPa or More

Dimensions/ Weight (Approx.)

W620 × D650 × H1,170 mm/ 153 kg

W620 × D600 × H1,460 mm, 205 kg
