Memory

16,128 readings (all channels enabled)

Reading Rate

1 reading every second up to 1 reading every 24 hours

Baud Rate

250,000

LED Indicators

Green, Blue & Red

Battery Life

3 years typical at a 1 minute reading rate

Material

ABS plastic

Dimensions

3.0 in x 3.5 in x 0.95 in (76.2 mm x 88.9 mm x 24.1 mm) - Data logger only

IP Rating

IP22

Operating Environment

-20 °C to +60 °C (-4 °F to +140 °F) 0 %RH to 95 %RH non-condensing

Required Interface Package

RFC1000

Approvals

US (FCC), CA (IC), CE, South Korea (KCC), China (CMIIT), Japan (LCIE)

Countries approved for use, purchase and distribution

Australia, Austria, Belgium, Bulgaria, Canada, Chile, China, Colombia, Croatia, Cyprus, Czech Republic, Denmark, Ecuador, Estonia, Finland, France, Germany, Greece, Honduras, Hungary, Iceland, Ireland, Israel, Japan, Latvia, Liechtenstein, Lithuania, Luxembourg, Malaysia, Malta, Mexico, New Zealand, Norway, Peru, Poland, Portugal, Romania, Saudi Arabia, Singapore, Slovakia, Slovenia, South Africa, South Korea, Spain, Sweden, Switzerland, Thailand, The Netherlands, Turkey, United Kingdom, United States, Venezuela, Vietnam

Internal Channel Temperature Sensor

Resistance Temperature Detector (RTD)

Internal Channel Temperature Range

-20 °C to +60 °C (-4 °F to +140 °F)

Internal Channel Temperature Resolution

0.01 °C (0.018 °F)

Internal Channel Temperature Calibrated Accuracy

±0.5 °C (0 °C to 55 °C)

Humidity Sensor

Relative Humidity Sensor

Humidity Range

0 %RH to 95 %RH

Humidity Resolution

0.1 %RH

Humidity Calibrated Accuracy

±3.0 %RH

Specified Accuracy Range

25 %RH to 75 %RH; +20 °C to +40 °C
Hysteresis Error 1 % typical, 3 % Maximum

RF Carrier Frequency

2.45 GHz IEEE 802.15.4 ultra-low power MadgeNET Wireless Transceiver with fully by-directional communication.

RF Baud Rate

250,000

Output Power

+0 dBm typical

Receiver Sensitivity

-95 dBm typical

Typical outdoors Line of sight

Up to 2,000 ft
