Part Number

Description

G410-1

Elcometer 410 Anemometer

Functions

Current wind speed, Average 3 second wind speed, Maximum wind gust, Data Hold

Measurement Units

Knots (kt), metres per second (m/s), kilometres per hour (km/h), miles per hour (mph), feet per minute (ft/min) and Beaufort Force (B)

Operating Range

0.4m/s to 60m/s (0.8 to 135.0mph)

Specification Range

0.4m/s to 40m/s (0.8 to 89.0mph)

On-axis Accuracy

±3% of reading or least significant digit, whichever is the greater

Off-axis Response

-1% at 5º, -2% at 10º, -3% at 15º

Calibration Drift

<1% after 100 hours operation at 7m/s

Resolution

0.1 kt, m/s, km/h, mph. 1 ft/min below 1999 ft/min, 10 ft/min above 2000 ft/min. 1 Beaufort (0 to 12)

Operating Temperature

-10ºC to +55ºC (14ºF to 131ºF)

Storage Temperature

-30ºC to +60ºC (-22ºF to 140ºF)

Power Supply

1 x CR2032 battery

Battery Life

Approximately 300 hours

Auto Switch Off

45 minutes after last key press

Dimensions

Instrument Only: 122 x 42 x 20mm (4.8 x 1.6 x 0.8”)
Instrument and Protective Cover: 122 x 46 x 26mm (4.8 x 1.8 x 1”)

Weight

Instrument Only: 65g (2.3oz)
Instrument and Protective Cover: 102g (3.6oz)

Packing List

Elcometer 410 Anemometer, protective cover, lanyard, 1 x CR2032 battery and operating instructions.
