Measurement Type:

Torsionally oscillating probe

Measurement Range:

1 to 3,000 (optional 12,000) cSt using an NIST traceable, Newtonian fluid measured at 25°C

Process Connections:

¾” standard, (1, 2½” tri-clamp or 3A design, optional)

Repeatability:

±1.0% of reading

Wetted Surfaces:

316L stainless steel

Sensor O-Ring:

Isolast for probe
Viton for chamber housing
(EDPM or Kalrez®, optional)

Temperature (Fluid):

-4°F to 248°F(-20°C to 120°C)

Pressure Range:

Vacuum to 200 psig max.

Viscosity Range (cSt):
(field selectable)

0 to 10, 0 to 50, 0 to 100,
0 to 250, 0 to 500,
0 to 1000, 0 to 1500,
0 to 2000, 0 to 12500

Analog Output (2):

4-20 mA (non-isolated)
CH1 = viscosity
CH2 = temperature

Serial Port (2):

Port 1 = RS232, simple, read only
Port 2 = ½ Duplex RS485,
Modbus RTU driver

Electronics Packaging:

Wall mount, NEMA-4 (IP65),
8” x 8” x 6”(203 x 203 x 152mm)
32°F to 104°F(0°C to 40°C)

Interconnecting Cable:

25 ft (7.6m) standard
Optional: 50 ft (15.2m), 75 ft (22.8m) and 100 ft (30.4m)

Supply Voltage:

18-30VDC or 115VAC/60 Hz or
230VAC/50 Hz
(±10% max),
power draw <1 amp
