Thiết bị kiểm tra độ căng trong quá trình thi công cáp

STYLE

MODEL

RANGE

TOLERANCE

RESOLUTION

CALIBRATION

LOW-TENSION

(5.5” wide)

LX-25-1

2 - 25 lb.

+/- 0.5 lb.

0.2 lb.

LX-1 meters are

custom-calibrated

for each material to

be measured.

Up to 10 calibrations

are available. A 10-foot

sample of each material

will be needed for the

calibration.

LX-50-1

5 - 50 lb.

+/- 1 lb.

0.2 lb.

LX-100-1

5 - 100 lb.

+/- 2 lb.

0.2 lb.

STANDARD

(5.5” wide)

LX-250-1

5 - 250 lb.

+/- 5 lb.

0.2 lb.

LX-500-1

25 - 500 lb.

+/- 10 lb.

1 lb.

WIDE

(8.5” wide)

Recommended

for large or stiff

materials

LX-100-W-1

5 - 100 lb.

+/- 2 lb.

0.2 lb.

LX-250-W-1

5 - 250 lb.

+/- 5 lb.

0.2 lb.

LX-500-W-1

25 - 500 lb.

+/- 10 lb.

1 lb.
